Uno Living

Uno Living modular bookcase entirely in metal. A solution that allows you to furnish any environment in the best possible way and with limitless versatility. Possibility to choose between different configurations and finishes. The historic system of Fantin hooked shelves is enriched with the inclusion of cantilevered shelves, which allow you to furnish any environment in the best possible way and with limitless versatility.

Technical details:

- Uprights in 30 x 30 mm tubular metal measuring 1.2 mm in thickness, fitted with plastic caps at the ends. Along the entire length, one side features slots with a pitch of 50 mm for the variable positioning of the click fasteners and hence of the shelves. The use of tubular metal, which provides higher performance levels than the more commonly used open section bars, ensures minimal torsional and flexural effects.

- Click fasteners made of pressed sheet metal, 2.5 mm thick. These fasteners are anchored to the uprights using two purpose-designed side fins which fit into the slots in the uprights. The shelves then click onto the upper fins of the actual click-fasteners. Every click fastener is designed to support 2 consecutive shelves simultaneously, enveloping and concurrently reinforcing the upright to which it is anchored.

- Standard shelves with a single depth of 30 cm, in 0.7 mm thick sheet metal folded three times along the two front sides to prevent accidents; omega-shaped reinforcements are envisaged on the underside to increase their load capacity. The four corners of the shelves are further reinforced with a 3 mm thick sheet
metal support that is designed to house the upright completely; this ensures perfect continuity between two consecutive shelves, without any gaps.
- Overhanging shelves (single or double overhanging) with a single depth of 30 cm, in 0.7 mm thick sheet metal folded three times along the accessible sides
to prevent accidents; omega-shaped reinforcements are envisaged on the underside to increase their load capacity. The housings of the uprights are further reinforced
with a 3 mm thick sheet metal support. The extension of the overhangings is always 25 cm.
